Standard DIN 8196 Sprockets
Products Standard DIN 8196 Sprockets
Code of Our Sprocket products
D40BTB25HD--------Strand No.
40-------Chain No.
B--------Type of Sprockets
TB-------Type of Bore
25-------Teeth No.
H--------Heat TreatmentNote:S-Simplex (Can be omitted)聽 D-Duplex T-Triplex Q-Quadplex
H= Heat Treatment
Black finishe......
Products Standard DIN 8196 Sprockets
Code of Our Sprocket products
D40BTB25H
- D--------Strand No.
- 40-------Chain No.
- B--------Type of Sprockets
- TB-------Type of Bore
- 25-------Teeth No.
- H--------Heat Treatment
Note:
- S-Simplex (Can be omitted)聽 D-Duplex T-Triplex Q-Quadplex
- H= Heat Treatment
- Black finished and Znic plated Sprockets will be marked in sales Contract.
- Material is C45, but some big sprockets are made from A3, Some Sprockets are made in Stainless Steel, Casting Iron, and Non-metal Material acc. to customer's requirements.
- Special Sprockets will be produced acc. to customers' drawings
Simplex |
Duplex |
Triplex |
 聽聽聽聽聽聽聽聽聽聽聽聽聽聽聽聽聽 Quadplex |
|
Chain No. |
Pitch |
Roller聽Dia脴 |
Chamfer Deep A |
Chamfer Width C |
Chamfer |
Pt |
Simplex |
Duplex, Triplex |
Quadplex |
||||||
|
聽t1 |
聽t2聽,t3 |
Teeth Width |
聽t4 |
Teeth Width |
|||||||||||
|
B2 |
B3 |
B2 |
B3 |
B4 |
|||||||||||
|
03 |
5 |
3.2 |
2.4 |
0.6 |
5 |
2.3 |
|||||||||
|
04 |
6 |
4 |
3 |
0.7 |
6 |
2.6 |
2.5 |
2.4 |
|||||||
|
05 |
8 |
5 |
4 |
1.0 |
8 |
5.6 |
2.8 |
2.7 |
8.3 |
13.9 |
2.6 |
8.2 |
13.8 |
19.4 |
|
|
06 |
9.525 |
6.35 |
4.8 |
1 |
10 |
10.2 |
5.3 |
5.2 |
15.4 |
25.6 |
5.0 |
15.2 |
25.4 |
35.6 |
|
|
081 |
12.7 |
7.75 |
6.4 |
1.3 |
13 |
3 |
|||||||||
|
082 |
12.7 |
7.75 |
6.4 |
1.3 |
3 |
2.2 |
|||||||||
|
083 |
12.7 |
7.75 |
6.4 |
1.3 |
3 |
4.5 |
|||||||||
|
084 |
12.7 |
7.75 |
6.4 |
1.3 |
3 |
4.5 |
|||||||||
|
085-1 |
12.7 |
7.75 |
6.4 |
1.3 |
3 |
5.9 |
|||||||||
|
085-2 |
12.7 |
8.51 |
6.4 |
1.3 |
3 |
5.9 |
|||||||||
|
08 |
12.70 |
8.51 |
6.4 |
1.3 |
13 |
13.9 |
7.2 |
7.0 |
21.0 |
34.9 |
6.8 |
20.7 |
34.6 |
48.5 |
|
|
10 |
15.875 |
10.16 |
7.9 |
1.6 |
16 |
16.6 |
9.1 |
9.0 |
25.6 |
42.2 |
9.0 |
25.6 |
42.2 |
58.8 |
|
|
12 |
19.05 |
12.07 |
9.5 |
2 |
19 |
19.5 |
11.1 |
10.8 |
30.3 |
49.8 |
10.8 |
30.3 |
49.8 |
69.3 |
|
|
16 |
25.40 |
15.88 |
12.7 |
2.5 |
26 |
31.9 |
16.2 |
15.8 |
47.7 |
79.6 |
15.8 |
47.7 |
79.6 |
111.5 |
|
|
20 |
31.75 |
19.05 |
15.9 |
3.5 |
32 |
36.5 |
18.5 |
18.2 |
54.6 |
91.0 |
18.2 |
54.6 |
91.0 |
127.5 |
|
|
24 |
38.10 |
25.4 |
19.1 |
4 |
38 |
48.4 |
24.1 |
23.6 |
72.0 |
120.3 |
23.6 |
72.0 |
120.3 |
168.7 |
|
|
28 |
44.45 |
27.94 |
22.2 |
5 |
44 |
59.6 |
29.4 |
28.8 |
88.4 |
148.0 |
28.8 |
88.4 |
148.0 |
207.6 |
|
|
32 |
50.80 |
29.21 |
25.4 |
6 |
51 |
58.6 |
29.4 |
28.8 |
87.4 |
146.0 |
28.8 |
87.4 |
146.0 |
204.6 |
|
|
40 |
63.50 |
39.37 |
31.8 |
8 |
64 |
72.3 |
36.2 |
35.4 |
107.7 |
180.0 |
35.4 |
107.7 |
180.0 |
252.3 |
|
|
48 |
76.20 |
48.26 |
38.1 |
9 |
76 |
91.2 |
43.3 |
42.5 |
133.7 |
224.9 |
42.5 |
133.7 |
224.9 |
316.1 |
|
|
56 |
88.90 |
53.98 |
44.5 |
11 |
89 |
106.6 |
50.7 |
49.6 |
156.2 |
262.8 |
49.6 |
156.2 |
262.8 |
269.4 |
|
|
64 |
101.60 |
63.5 |
50.8 |
13 |
102 |
119.9 |
57.9 |
56.7 |
176.6 |
296.5 |
56.7 |
176.6 |
296.5 |
416.4 |
|
|
72 |
114.30 |
72.39 |
57.2 |
15 |
114 |
136.3 |
65.2 |
63.8 |
200.1 |
336.4 |
63.8 |
200.1 |
336.4 |
472.7 |
|
Note:1H=1/2(Dp-Dh) Dp=P/Sin180/2聽Dh=P ctg 180/2-1.04h2-0.76
Dp: Pitch聽Dh:聽聽Max Dia. of Hub ( Grrove Dia.)聽h2:Height of Chain Plate
2. teeth Wide more than 4 Strands: Bn=(n-1)Pt+t4(n4)
