EP403T Planetary Track Drive EP403W Winch Drive EP603L Wheel Drives

EP403T2 TRACK DRIVES-(703C2H), EP403W2 WINCH DRIVES, EP603L2 WHEEL DRIVESTechnical specificationMax.Output Torque (N.m)Ratio (i)Recommend Hydraulic MotorMax. input speed (rpm)Brake torque (N.m)Brake work pressure (bar)EP402TEP402WEP602L7000----700018.6 24.4 29.3 37.1EATON, 2K SAE A adopt 蠁25 Shaft Z......

Send Inquiry

Product Description

EP403T2 TRACK DRIVES-(703C2H),
EP403W2 WINCH DRIVES,
EP603L2 WHEEL DRIVES

Technical specification

Max.Output Torque (N.m)			Ratio (i)	Recommend Hydraulic Motor	Max. input speed (rpm)	Brake torque (N.m)	Brake work pressure (bar)
EP402T	EP402W	EP602L
7000	----	7000	18.6 24.4 29.3 37.1	EATON, 2K SAE A adopt 蠁25 Shaft Z13,DP16/32 Spline	4000	----	----

- Input rotation opposite output rotation.
- Other ratio and other input type can be specially designed.
- If with manual disconnect device, please add mark聽鈥淢鈥澛?/strong>at the end of the product model.
- Without brake.
