Raydafon Gears

Your Partner for High-Performance Automotive & Industrial Gears
EP407AT2/3 Planetary Track Drive EP407AW2/3 Winch Drives

EP407AT2/3 Planetary Track Drive EP407AW2/3 Winch Drives

EP407AT2, AT3 TRACK DRIVES (GFT26T2,GFT26T3) EP407AW2, AW3 WINCH DRIVES (GFT26W2,GFT26W3)Technical specificationMax.Output Torque (N.m)Ratio (i)Recommend Hydraulic MotorMax. input speed (rpm)Brake torque (N.m)Brake work pressure (bar)EP407ATEP407AW260001800038*, 43.2* 50.4*, 61* 63.2, 70.3 80, 94.4 ......
Send Inquiry
Product Description

EP407AT2, AT3 TRACK DRIVES (GFT26T2,GFT26T3)
EP407AW2, AW3 WINCH DRIVES (GFT26W2,GFT26W3)

EP407AT2/3 Planetary Track Drive EP407AW2/3 Winch Drives

Technical specification

Max.Output Torque
(N.m)

Ratio
(i)

Recommend Hydraulic Motor

Max. input speed
(rpm)

Brake torque
(N.m)

Brake work pressure
(bar)

EP407AT

EP407AW

26000

18000

38*, 43.2*
50.4*, 61*
63.2, 70.3
80, 94.4
110.8
136

A2FE80路90
A2FE45路56路63
A6VE55路80

4000

530
~
430

20-50
    • Input rotation opposite output rotation.
    • Other ratio and other input type can be specially designed.
    • Gear box with * marked ratio is 2 stage.
