Gearbox for Agricultural Machinery 700 Series

Gearbox for Agricultural Machinery 700 Series

Features:

• Two-piece aluminum housing for high strength, corrosion resistance, and thermal capacity
• Precision machined for exact gear mesh and bearing preload
• Precision forged gears are offered in a 3:1 ratio
• Tapered roller bearings provide increased load capacity and bearing life
• 1.75" input shaft and 2.75" output shaft made of high strength steel standard
• Filled with 80W90 gear lubricant and leak tested before shipment
• The 700 Series weighs approximately 120 lbs. including oil
• Contact Ever-Power Gearbox for your special requirements

RATING CHARTS
